Boston Tech BE-105 Paraffin Bath User Manual

Introducción

The Boston Tech BE-105 Paraffin Bath is designed to provide therapeutic and aesthetic treatments for hands and feet. Utilizing thermotherapy, it helps alleviate muscle pain, rheumatoid arthritis, osteoarthritis, tendinitis, and edema. Additionally, it stimulates blood circulation and provides deep hydration for rough and dry skin, leaving it soft and healthy.

Contenido del paquete

Al desembalar, asegúrese de que todos los componentes estén presentes:

• Boston Tech BE-105 Paraffin Bath Unit
• 2 bags of paraffin wax (450g each)
• 30 protective plastic bags
• Cotton mittens/gloves
• Insulating grille
• Cepillar
• Manual de usuario

Image: The Boston Tech BE-105 Paraffin Bath unit, its packaging, and included accessories such as paraffin wax, plastic bags, and a brush.

Instrucciones de instalación

1. Colocación: Place the paraffin bath unit on a stable, flat, and heat-resistant surface. Ensure it is away from water sources and out of reach of children.
2. Insertar rejilla: Place the insulating grille at the bottom of the paraffin bath. This prevents direct contact between the heating element and the paraffin wax.
3. Add Paraffin Wax: Open the paraffin wax bags and place the wax blocks into the bath. The unit has a capacity of approximately 5 liters. Ensure the wax level is between the MIN and MAX indicators.
4. Conecte la electricidad: Conecte el cable de alimentación a una toma eléctrica adecuada.
5. Calentamiento inicial: Turn the temperature control dial to the 'HI' setting to begin melting the paraffin wax. The wax typically melts and is ready for use in approximately 30 minutes. The unit features a timer to indicate when the paraffin is ready.

Image: The Boston Tech BE-105 Paraffin Bath showing its dimensions (Length: 38 cm, Width: 24 cm, Depth: 24 cm) and key features like temperature range (30°C - 85°C), 30-minute melting time, and 3000ml capacity.

Imagen: Un primer plano view of the Boston Tech BE-105 Paraffin Bath with melted green paraffin wax, indicating the unit is in operation and ready to melt wax in 30 minutes.

Instrucciones de funcionamiento

1. Ajuste de temperatura: Once the paraffin wax has fully melted, adjust the temperature control dial to the 'LO' or desired 'WARM' setting. The adjustable temperature range is 30°C to 85°C. Allow the wax to cool slightly to a comfortable temperature before use. The unit will provide an audible signal when the wax is ready.
2. Prepárese para el tratamiento: Ensure your hands or feet are clean and dry. You may apply a moisturizer before treatment for enhanced hydration.
3. Proceso de inmersión: Slowly dip your hand or foot into the melted paraffin wax, ensuring full coverage. Immediately withdraw and allow the wax to solidify for a few seconds. Repeat this process 3-5 times to build up several layers of wax.
4. Cubierta: After the final dip, immediately cover the treated hand or foot with one of the provided plastic bags, then place it inside a cotton mitten/glove to retain heat.
5. Duración del tratamiento: Keep the wax on for 10-15 minutes to allow for maximum heat penetration and hydration.
6. Eliminación: Gently peel off the solidified wax. The wax can be discarded after use. Do not reuse wax that has been removed from the skin.

Image: A hand being immersed in the melted green paraffin wax within the Boston Tech BE-105 Paraffin Bath, illustrating the application process.

Image: A close-up of the temperature control dial on the Boston Tech BE-105 Paraffin Bath, showing settings for 'OFF', 'LO', and 'HI', with an indicator light.

Mantenimiento

1. Limpieza: After use, ensure the unit is unplugged and completely cooled. Remove any remaining solidified wax. Use a soft, damp cloth to wipe the interior and exterior surfaces. Do not use abrasive cleaners or immerse the unit in water.
2. Reemplazo de cera: For optimal hygiene and performance, it is recommended to replace the paraffin wax regularly, especially if it appears discolored or contaminated.
3. Almacenamiento: Store the paraffin bath in a cool, dry place, away from direct sunlight and extreme temperatures. Ensure the lid is securely closed to protect the wax from dust.

Solución de problemas

• La unidad no calienta: Ensure the power cord is securely plugged into a functional outlet and the temperature dial is set to 'LO' or 'HI'. Check for any tripped circuit breakers.
• La cera no se derrite: Verify that the unit has been on the 'HI' setting for at least 30 minutes. If the wax is old or has been exposed to moisture, it may take longer to melt or may need replacement.
• Overheating/Unusual Odor: Immediately unplug the unit and discontinue use. Contact customer support for assistance.

For any issues not covered here, please refer to the full user manual or contact Boston Tech customer support.

Presupuesto

Información de garantía

The Boston Tech BE-105 Paraffin Bath comes with a Garantía de cinco años from the date of purchase. This warranty covers manufacturing defects and ensures the product's quality and performance under normal use. Please retain your proof of purchase for any warranty claims.

Apoyo

For further assistance, technical support, or to inquire about replacement parts, please contact Boston Tech customer service. Refer to the product packaging or the official Boston Tech websitio para detalles de contacto.
