PetSafe 600 Meter Remote Trainer User Manual

1. Introducción

The PetSafe 600 Meter Remote Trainer is designed to assist in training your dog through various forms of communication. This system features a rechargeable, waterproof receiver collar and a remote transmitter. It offers three types of stimulation: tone, vibration, and 1-15 levels of static stimulation, with a safety lock for levels 8-15. The remote has a backlit digital display and a two-button design for easy operation. This trainer is suitable for dogs weighing 8 lbs and up, with neck sizes up to 28 inches. It can be expanded to train up to two dogs with additional collars (sold separately).

Image 1.1: The PetSafe 600 Meter Remote Trainer, showing the remote transmitter and the receiver collar.

2. Componentes del producto

The PetSafe 600 Meter Remote Trainer system includes the following items:

• Transmisor remoto
• Adjustable Receiver Collar
• Cable de carga USB
• Herramienta de luz de prueba
• Puntos de contacto largos
• Puntos de contacto cortos
• Acollador

Image 2.1: Contents of the PetSafe 600 Meter Remote Trainer package.

3. Configuración

3.1 Carga de los dispositivos

Both the remote transmitter and the receiver collar are rechargeable. Use the provided USB charging cable and a wall adapter (included) to charge both units. A full charge typically provides up to 40 hours of operation. Ensure both devices are fully charged before initial use.

3.2 Ajuste del collar receptor

1. Select the appropriate contact points (short or long) based on your dog's coat length. The contact points must make direct contact with your dog's skin.
2. Place the receiver collar on your dog's neck so that the contact points are underneath, centered on the neck.
3. Adjust the strap to ensure a snug fit. You should be able to fit one finger snugly between the strap and your dog's neck. The collar should not be too loose, as this can reduce effectiveness and cause irritation.
4. Recorte el exceso de longitud de la correa si es necesario.

Image 3.1: Proper placement of the receiver collar on a dog.

3.3 Testing the Collar

Before using the static stimulation, it is recommended to test the collar using the provided test light tool. Attach the test light to the contact points and activate the static stimulation on the remote. The test light should illuminate, indicating the static function is working correctly.

4. Instrucciones de funcionamiento

4.1 Funciones del transmisor remoto

The remote transmitter features a backlit digital display and dedicated buttons for different stimulation types:

• Tono (pitido): Delivers an audible tone to the receiver collar.
• Vibración: Activates a vibration on the receiver collar.
• estimulación estática: Provides static stimulation at levels 1-15. Levels 8-15 are equipped with a safety lock feature to prevent accidental high-level stimulation.
• Adjuster Buttons: Used to select the stimulation level (1-15) for static stimulation.
• Dog 1 / Dog 2 Selector: Allows switching between two collars if an additional collar is paired.

Image 4.1: Remote Transmitter layout and functions.

4.2 Range and Usage

The PetSafe 600 Meter Remote Trainer offers a range of up to 600 meters (approximately 656 yards), providing effective communication over longer distances. This makes it suitable for various outdoor activities and training scenarios.

Image 4.2: The trainer offers static, vibration, and tone options for behavior correction.

5. Pautas de capacitación

Effective training with the PetSafe Remote Trainer requires consistency and positive reinforcement. Start with the lowest effective stimulation level and gradually increase if necessary. Always pair the stimulation with a command and praise your dog for correct responses.

• Begin training in a quiet, distraction-free environment.
• Use the tone or vibration functions as initial warnings before applying static stimulation.
• The static stimulation should be used as a deterrent for unwanted behaviors, not as punishment.
• Keep training sessions short and positive.
• Never leave the collar on your dog for more than 12 consecutive hours.

6. Mantenimiento

6.1 Limpieza

Limpie periódicamente el collar receptor y los puntos de contacto con adamp cloth to prevent dirt buildup and ensure proper skin contact. Ensure the devices are dry before charging.

6.2 Cuidado de la batería

Both the remote and collar contain rechargeable Lithium-Ion batteries. For optimal battery life, avoid fully discharging the batteries frequently. Recharge them when the battery indicator shows low. The devices are waterproof (IP67 rated), but ensure charging ports are dry before connecting the charger.

Image 6.1: The receiver collar is waterproof and rechargeable.

7. Solución de problemas

• Sin estimulación: Ensure the collar is properly fitted and the contact points are touching your dog's skin. Check if the remote and collar are charged. Use the test light tool to verify static stimulation functionality.
• Rango Reducido: Environmental factors such as terrain, weather, and metallic objects can affect the range. Ensure the remote's antenna is not obstructed.
• Collar Not Holding Charge: Ensure the charging cable is securely connected to both the collar and the power source. If the issue persists, the battery may need servicing.
• Remote Display Not Working: Check the remote's battery level. If the display remains blank after charging, contact customer support.

8. Especificaciones

9. Garantía y soporte

For product support, warranty information, or assistance with your PetSafe 600 Meter Remote Trainer, please contact PetSafe Customer Care. They can provide guidance on product usage, troubleshooting, and replacement parts.

• Atención al cliente en EE. UU.1-800-845-3274
• Canada Customer Care1-800-457-3911

Please refer to your product packaging or the official PetSafe webSitio para obtener los detalles de garantía más actualizados.
