Introducción
This manual provides essential information for the safe and efficient operation, installation, and maintenance of your Klimaire 9,000 BTU PTAC Heat Pump Air Conditioner. Please read this manual thoroughly before installing or operating the unit and retain it for future reference. This unit is designed to provide year-round comfort with both cooling and heating capabilities, featuring R-32 refrigerant for enhanced efficiency and Wi-Fi connectivity for convenient control.
Información de seguridad
Always follow basic safety precautions when using electrical appliances to reduce the risk of fire, electric shock, and injury. This unit operates on 208-230V, single-phase, 60Hz power. Ensure proper grounding and use a dedicated 20A 3-prong circuit (Type LCDI 6-20P). Do not operate the unit with a damaged power cord or plug. Keep children and pets away from the unit during operation. Refer to local electrical codes for installation requirements. Only qualified personnel should perform installation and servicing.
Producto terminadoview
Características principales
- Seamless Replacement: Designed for compatibility with most standard 42" x 16" slide-in wall sleeves.
- Eficiencia excepcional: EER 11.4, Cooling Capacity: 9,300/9,200 BTU/h, Heat Pump Heating Capacity: 8,100 / 7,900 BTU/h, Auxiliary 3.5 kW Electric Heating Capacity: 10,900 / 8,900 BTU/h.
- Modern Refrigerant: Utilizes R-32 refrigerant for improved environmental performance and efficiency.
- Control inteligente Wi-Fi enabled for smartphone control via a dedicated app.
- Interfaz fácil de usar: Digital display control panel with push buttons for easy operation.
- Funcionamiento silencioso: Engineered for reduced noise levels, ideal for hospitality and residential settings.
- Filtros lavables: Easily removable and washable air filters for convenient maintenance.
- Aplicación versátil: Suitable for hotels, motels, nursing homes, workshops, and room additions.
Componentes avanzados
The Klimaire PTAC unit incorporates several advanced components for optimal performance and durability.
Figure 1: Advanced internal components of the Klimaire PTAC unit.
Qué incluye
Your Klimaire PTAC unit package includes the following items:
- 9,000 BTU PTAC Heat Pump Air Conditioner (R-32 refrigerant) with backup 3.5kW Heater
- Control remoto inalámbrico
- Kit de drenaje
- Etiqueta engomada del panel de control
- 20A Power Cord (Type LCDI 6-20P)
Figure 2: Contents included with your Klimaire PTAC unit.
Configuración
Requisitos de instalación
The Klimaire PTAC unit is designed for through-the-wall installation. For new installations, a compatible 42" x 16" wall sleeve and a rear grille are required (not included with the unit). Ensure the installation location provides adequate clearance for airflow and maintenance.
Figure 3: Key dimensions of the Klimaire PTAC unit.
Figure 4: Dimensions and compatibility with standard wall sleeves and grilles.
Sleeve and Grille Assembly
Proper assembly of the PTAC sleeve and grille is crucial for secure installation and optimal performance. The following video demonstrates the assembly process.
Video 1: Detailed instructions on how to assemble the PTAC sleeve and grille for installation.
Instalación del kit de drenaje
The included drain kit helps manage condensate. Install it according to the instructions provided in the video above or the separate drain kit manual to ensure proper water drainage.
Conexión de energía
The unit requires a 20A 3-prong plug (Type LCDI 6-20P) and operates on 208-230V, single-phase, 60Hz. Ensure the electrical outlet is compatible and properly grounded before plugging in the unit.
Figure 5: Details of the 20A 3-prong power plug and receptacle.
Instrucciones de funcionamiento
Operación del panel de control
The unit features an intuitive digital display control panel for direct adjustments. Use the push buttons to set the desired temperature, select operating modes (Cool, Heat, Fan, Dry), and view operational codes or error messages for quick troubleshooting.
Figure 6: Digital display control panel for direct unit operation.
Control remoto inalámbrico
A wireless remote control is included for convenient adjustment of settings from a distance. The remote allows you to change temperature, mode, and fan speed without directly interacting with the unit's control panel.
Control inteligente Wi-Fi
For enhanced convenience, control your PTAC unit using your smartphone with the dedicated Wi-Fi app. This feature allows you to access all comfort settings and manage your unit remotely.
Figure 7: Smartphone integration for Wi-Fi smart control.
Mantenimiento
Limpieza del filtro de aire
Regular cleaning of the air filters is essential for maintaining optimal performance and air quality. The unit features easily removable and washable polypropylene filters.
- To clean, gently pull out the air filters from the front panel.
- Wash the filters with mild soap and warm water.
- Enjuágalos bien y déjalos secar al aire por completo antes de volver a colocarlos.
- Frequency of cleaning depends on usage and environmental conditions, typically every 2-4 weeks.
Figura 8: Filtro de aire lavable para fácil mantenimiento.
Solución de problemas
If your Klimaire PTAC unit is not operating correctly, refer to the following common issues and solutions before contacting customer support.
| Problema | Posible causa | Solución |
|---|---|---|
| La unidad no se enciende | No power, tripped circuit breaker, or unit is off. | Check power cord connection, reset circuit breaker, ensure unit is turned on. |
| Refrigeración/calefacción insuficiente | Dirty air filter, blocked air intake/outlet, incorrect mode setting, or room size exceeds capacity. | Clean air filter, clear obstructions, select appropriate mode, ensure unit matches room size. |
| Ruido inusual | Loose parts, fan obstruction, or unit not level. | Check for loose components, remove obstructions, ensure unit is installed on a level surface. |
| Fuga de agua | Blocked drain hose or improper drain kit installation. | Clear any blockages in the drain hose, verify correct drain kit assembly. |
Presupuesto
Detailed technical specifications for the Klimaire 9,000 BTU PTAC Heat Pump A/C R-32 unit.
| Especificación | Valor |
|---|---|
| Nombre de marca | Clima |
| Información del modelo | PTHP09H352-KC-3 |
| Peso del artículo | 104 libras |
| Dimensiones del producto (Unidad) | 21 x 16 x 16 pulgadas |
| Dimensiones del producto (total) | 42" de profundidad x 16" de ancho x 16" de alto |
| Eficiencia (VISIDENTE) | 12.8 |
| Capacidad de enfriamiento | 9,300/9,200 BTU/h (0.75 Tons) |
| Heat Pump Heating Capacity | 8,100 / 7,900 BTU/h |
| Capacidad de calentamiento eléctrico auxiliar | 3.5 kW (10,900 / 8,900 BTU/h) |
| Nivel de ruido | 49.5 decibelios |
| Tipo de instalación | Packaged (Through-the-Wall) |
| Requisitos de energía | 208-230 V, monofásica, 60 Hz |
| Enchufe eléctrico | 20A 3-prong (Type LCDI 6-20P) |
| Refrigerante | R-32 |
| Elementos calefactores | 2 |
| Color | Blanco |
| Cobertura del área del piso | 350 pies cuadrados |
Figure 9: Part 1 of the detailed technical specifications table.
Figure 10: Part 2 of the detailed technical specifications table.
Figure 11: Part 3 of the detailed technical specifications table.
Garantía
Klimaire products are manufactured to high-quality standards. This product comes with a limited warranty covering defects in materials and workmanship under normal use. Please refer to the warranty card included in your product packaging for specific terms, conditions, and duration of coverage. Keep your proof of purchase for warranty claims.
Apoyo
For technical assistance, troubleshooting beyond this manual, or warranty inquiries, please contact Klimaire customer support. Have your model number (PTHP09H352-KC-3) and purchase date ready when you call. You can find contact information on the Klimaire websitio web o en la documentación de su producto.
