1. Introducción
The Weltool W35A is a compact, high-performance white light LED weapon-mounted light designed for tactical and professional use. It features a powerful beam, durable construction, and versatile mounting options, making it suitable for various applications in low-light environments.
Image 1.1: Weltool W35A White Light LED Weapon Mounted Light, showcasing su diseño compacto.
2. Información de seguridad
- Always handle firearms safely. Ensure the firearm is unloaded and pointed in a safe direction before installing or removing the light.
- Do not look directly into the light beam or shine it into the eyes of people or animals. The high intensity light can cause temporary vision impairment or eye damage.
- Mantenga la luz fuera del alcance de los niños.
- Use only the specified battery type (Lithium Ion) and ensure correct polarity during installation.
- Avoid exposing the light to extreme temperatures or direct flame.
3. Contenido del paquete
Verifique que todos los artículos estén presentes en el paquete:
- Weltool W35A Weapon Mounted Light
- 1 batería de iones de litio (incluida)
Image 3.1: Components of the Weltool W35A, including the light head, body, tail cap, and battery.
4. Características del producto
- High Intensity Beam: 89,600 candela with a beam distance of 653 yards.
- Brillo: 686 lumens white light output.
- Diseño compacto: Light head diameter of 32.5mm.
- Construcción duradera: Made from aluminum, IP67 waterproof and dustproof, shock and vibration resistant.
- Montaje versátil: Features 2 mounting holes compatible with various rail mounts (e.g., M-LOK, Picatinny, KeyMod, MIL-STD-1913, STANAG 2324, STANAG 4694, Weaver).
- Cambio táctico: Allows for momentary activation (light press) or constant-on (locked) operation.
- Protecciones avanzadas: Silent On/Off, Lock Function, Reverse Polarity Protection, Low-Voltage Warning, Battery Over-discharge Protection, No PWM, Noise and Temperature Control Protection.
Imagen 4.1: Primer plano view of the Weltool W35A light head, highlighting its robust construction.
5. Configuración e instalación
5.1 Instalación de la batería
- Unscrew the tail cap from the light body.
- Insert the included Lithium Ion battery with the positive (+) end facing towards the light head.
- Screw the tail cap back on securely. Ensure it is fully tightened to maintain waterproof sealing.
Imagen 5.1: Desmontado view of the light showing battery insertion point.
5.2 Montaje de la luz
The W35A features two mounting holes on its body, allowing for attachment to various tactical rails using compatible mounts (e.g., Weltool PM4, not included). Ensure the firearm is unloaded and safe before proceeding.
- Select a suitable rail mount (e.g., M-LOK, Picatinny) that is compatible with your firearm and the W35A's mounting holes.
- Attach the chosen rail mount to the W35A light body using appropriate screws and tools.
- Securely attach the light with the mounted adapter to your firearm's rail system. Ensure all screws are tightened to prevent movement during use.
Image 5.2: Detail of the W35A body showing the two mounting holes for rail attachments.
Image 5.3: The Weltool W35A light securely mounted on tactical equipment.
6. Operación
The W35A utilizes a tactical tail switch for operation.
Image 6.1: Close-up of the tactical tail switch on the Weltool W35A.
- Encendido momentáneo: Lightly press the tactical switch to activate the light. Release the switch to turn the light off. This provides silent operation.
- Encendido constante: Fully press the tactical switch until it clicks to lock the light in the "on" position. Press again to turn the light off.
The light features a single output mode. The advanced protections include a low-voltage warning and battery over-discharge protection to ensure optimal battery life and performance.
Image 6.2: The Weltool W35A illuminating an area with its powerful beam.
7. Mantenimiento
- Limpieza: Limpie la luz con un paño suave yamp Paño. No utilice limpiadores abrasivos ni disolventes.
- juntas tóricas: Periodically inspect the O-rings for wear and tear. Lubricate them with silicone grease to maintain waterproof integrity. Replace if damaged.
- Cuidado de la batería: If the light will not be used for an extended period, remove the battery to prevent leakage. Store batteries in a cool, dry place.
- Trapos: Mantenga las roscas limpias y ligeramente lubricadas para garantizar un funcionamiento suave y un sellado adecuado.
Image 7.1: The Weltool W35A demonstrating its waterproof capabilities under simulated rain.
8. Solución de problemas
| Problema | Posible causa | Solución |
|---|---|---|
| La luz no se enciende. |
|
|
| La luz parpadea o es tenue. |
|
|
| Entrada de agua. |
|
|
9. Especificaciones
| Modelo | W35A |
| Fuente de luz | CONDUJO |
| Brillo | 686 lúmenes |
| Candela | 89,600 cd |
| Distancia del haz | 653 yardas |
| Fuente de poder | Funciona con pilas |
| Tipo de batería | 1 x batería de iones de litio (incluida) |
| Volumentage | 3.7 voltios |
| Material | Aluminio |
| Resistencia al agua | IP67 (impermeable) |
| Características especiales | Light-weight, Long Range, Dustproof, Tactical Switch, Silent On/Off, Lock Function, Reverse Polarity Protection, Low-Voltage Warning, Battery Over-discharge Protection, No PWM, Noise and Temperature Control Protection |
| Dimensiones (paquete) | 6.1 x 4.37 x 2.32 pulgadas |
| Peso del artículo | 8.1 onzas |
10. Garantía y soporte
For warranty information or technical support, please contact Weltool customer service. Refer to the official Weltool websitio o su documentación de compra para obtener los datos de contacto más actualizados.
Fabricante: Herramienta de bienestar
Websitio: www.weltool.com
