1. Introducción
Thank you for choosing the Woputne LED Desk Lamp with Dual Heads, Model JB510. This manual provides essential information for the safe and efficient operation of your new desk lampLéalo detenidamente antes de usarlo y consérvelo para futuras consultas.
Este lamp features a dual-head design, offering versatile lighting with 5 color modes and 10 brightness levels. It is designed for various environments including home offices, bedrooms, study areas, and craft spaces.
Figure 1: Woputne LED Desk Lamp with Dual Heads in use, demonstrating phone charging capability.
2. Contenido del paquete
Verifique que todos los artículos enumerados a continuación estén incluidos en su paquete:
- 1 x Woputne LED Desk Lamp (Model JB510)
- 1 x 5V 2A Mains Plug
- 1 x cable USB
- 1 x Manual de usuario (este documento)
3. Instrucciones de seguridad
- Asegúrese de que la fuente de alimentación voltage coincide con lampRequisitos de (5 V).
- No desmonte ni modifique el lamp.
- Evite exponer el lamp to water or high humidity. This product is not waterproof.
- Mantén la lamp lejos de fuentes de calor y luz solar directa.
- Desconecte el lamp de la toma de corriente antes de limpiarlo o si no se utilizará durante un período prolongado.
- No lo use si el cable de alimentación o el enchufe están dañados.
4. Configuración
- Deshacer: Retire con cuidado todos los componentes del embalaje.
- Posicionamiento: Coloque la lamp base sobre una superficie estable y plana.
- Conecte la electricidad: Inserte el cable USB en el lamp's 5V 2A USB Charging input-port (labeled 'IN' on the back of the base). Connect the other end of the USB cable to the provided mains plug, then plug the mains plug into a suitable wall outlet.
- Interruptor de encendido manual: Locate the manual 'ON/OFF' sliding button on the back of the lamp base. Ensure this switch is in the 'ON' position for the lamp to function. If the button is 'OFF', the desk lamp no se encenderá.
Figura 2: Detalle de la lamp base, highlighting the USB input port and the manual ON/OFF switch.
5. Instrucciones de funcionamiento
The Woputne LED Desk Lamp features intuitive touch controls located on the base.
Figure 3: Touch control panel and visual representation of light modes and brightness levels.
5.1 Encendido y apagado
- Ensure the manual switch on the back is 'ON'.
- Toca el Botón de encendido (símbolo: círculo con línea vertical) en la base para girar la lamp Encendido o apagado.
5.2 Ajuste de los modos de color
- Toca el Botón de modo (symbol: book) to cycle through 5 different color temperatures (3000K to 6000K).
5.3 Ajuste de los niveles de brillo
- Toca el Botón de brillo (symbol: gear) to cycle through 10 brightness levels.
5.4 Función de memoria
- El lamp will remember your last used brightness and color mode settings when turned off and on again, provided the main power is not disconnected.
- Nota: Si el lamp is unplugged or experiences a power outage, it will reset to factory default settings.
5.5 Temporizador de apagado automático
- Toca el Botón del temporizador (símbolo: reloj) to activate the 45-minute auto-off timer. This is useful for nighttime reading.
6. Características
6.1 Dual Head Design
El lamp features a unique dual-head design, allowing for flexible lighting. The two light bars can be adjusted independently or together to concentrate light for specific tasks or disperse it for broader illumination. The total length of the lamp head is 56cm, with each single head measuring 25cm.
Figure 4: Dual head design for wide and flexible lighting.
6.2 Adjustable Arm and Base
El lamp offers extensive adjustability for optimal positioning:
- El lamp arm is 180° flexible.
- The base can be adjusted up to 135°.
- The foldable design enhances portability and storage.
Figure 5: Adjustable arm and base for flexible positioning.
6.3 puertos de carga USB
El lamp includes a 5V 1A USB output port on the base, allowing you to charge compatible devices such as smartphones while using the lamp.
Figure 6: USB charging port on the lamp base.
7. Mantenimiento
- Limpieza: Asegúrese de que lamp is unplugged before cleaning. Use a soft, dry cloth to wipe the surface. Do not use abrasive cleaners or solvents.
- Almacenamiento: Cuando no esté en uso, guarde el lamp en un lugar fresco y seco, alejado de la luz solar directa y de la humedad.
8. Solución de problemas
| Problema | Posible causa | Solución |
|---|---|---|
| Lamp no se enciende. | 1. Manual ON/OFF switch is in 'OFF' position. 2. Power cable is not properly connected. 3. Apagartage or lamp Reiniciar. | 1. Ensure the manual switch on the back of the base is 'ON'. 2. Check all power connections, including the mains plug and USB cable. 3. If unplugged or power was lost, the lamp may need to be turned on via the touch control. |
| Lamp settings (mode/brightness) reset. | Power was disconnected or there was a power outage. | This is normal behavior. Re-adjust your preferred settings. The memory function only works when the lamp is turned off via touch control and remains plugged in. |
| Lamp head/arm does not stay in position. | Joints may be loose or the weight distribution is uneven. | Ajustar el lamp head and arm to a balanced position. Ensure the joints are not excessively loose. |
| El puerto de carga USB no funciona. | 1. Dispositivo no compatible. 2. Elamp No encendido. 3. Problema con el cable. | 1. Ensure your device is compatible with 5V 1A USB charging. 2. La lamp must be powered on for the USB charging port to function. 3. Try a different USB cable. |
9. Especificaciones
Figura 7: Dimensiones del producto.
| Especificación | Detalle |
|---|---|
| Nombre del modelo | JB510 |
| Marca | Woputné |
| Tipo de fuente de luz | CONDUJO |
| Quétage | 5 vatios |
| Volumentage | 5 voltios |
| Brillo | 270 lúmenes |
| Temperatura de color | 5 modes (3000K to 6000K) |
| Niveles de brillo | 10 niveles |
| Método de control | Tocar |
| Características especiales | Manual ON/OFF Switch, Memory Function, 45-minute Auto-Off Timer, USB Charging Port (5V 1A output) |
| Material | Aluminio, Plástico |
| Dimensiones del producto | 5.2" de profundidad x 1.81" de ancho x 15.35" de alto (aprox. 13.2 cm de profundidad x 4.6 cm de ancho x 39 cm de alto) |
| Peso del artículo | 1.47 libras (aprox. 665 gramos) |
| Longitud del cable | 39.37 Inches (approx. 100cm) |
| Código Postal | 715377635471 |
Figure 8: Energy Efficiency Label. For more details, visit eprel.ec.europa.eu/qr/1481462.
10. Garantía y soporte
Woputne is committed to providing quality products. For any questions, concerns, or support needs regarding your LED Desk Lamp, please contact our customer service. Specific warranty details may vary; please refer to your purchase documentation or contact the seller for more information.
We aim to ensure customer satisfaction and are available to assist with product inquiries or operational guidance.
