Manual de instrucciones del sillón reclinable giratorio eléctrico COLAMY 270

1. Introducción e información de seguridad

Thank you for choosing the COLAMY 270 Power Swivel Glider Recliner Chair. This manual provides essential instructions for assembly, operation, and maintenance to ensure safe and optimal use of your product. Please read this manual thoroughly before use and retain it for future reference.

Advertencias de seguridad importantes:

• Capacidad máxima de peso: Do not exceed the maximum weight recommendation of 300 pounds (136 kg). Exceeding this limit may result in injury or damage to the chair.
• Niños y mascotas: Keep children and pets away from the chair's moving parts, especially during recline or swivel operations.
• Cables de alimentación: Ensure all power cords are properly routed to avoid tripping hazards or damage. Do not place the chair on the power cord.
• Superficie estable: Coloque siempre la silla sobre una superficie plana y estable.
• Uso previsto: Use this chair only for its intended purpose as a seating and reclining furniture item. Avoid standing on the chair or using it as a step stool.
• Mantenimiento: Regularly inspect the chair for any loose parts or damage. Do not use if any components are damaged.

2. Contenido del paquete

Verifique que todos los componentes estén presentes antes de comenzar el ensamblaje:

• Sofa Back (B)
• Cojín del asiento (A)
• Support Frame (C)
• Mobile Frame (D)
• iPad Frame (E)
• Frame Nut (F)
• Power Cable (G)
• Power Supply (H)
• Manual de usuario (este documento)

3. Configuración y montaje

Follow these steps to assemble your COLAMY Power Swivel Glider Recliner Chair. It is recommended to have two people for assembly.

1. Step 1: Connect Sofa Back to Seat Cushion. Carefully align the Sofa Back (B) with the Seat Cushion (A) and push down until the connection is secure. Once connected, secure the Sofa Back cover to the bottom of the Seat Cushion using the Velcro fasteners.


   Image: Connecting the sofa back to the seat cushion and securing with Velcro.

2. Step 2: Connect Power Cables. Connect the Power Cable (G) to the Power Supply (H). Ensure the connection is firm. Then, connect the power supply to a wall outlet and switch it on.


   Image: Connecting the power cable to the power supply.

3. Step 3: Attach Support Frame. Use the Frame Nut (F) against the bottom of the frame base on the right side of the sofa. Rotate the Support Frame (C) until the connection is secure.
4. Step 4: Attach Device Holders. Connect either the iPad Frame (E) or Mobile Frame (D) to the top of the Support Frame (C) until the connection is secure. These holders are removable and interchangeable.


   Image: Attaching the device holder to the support frame.

4. Instrucciones de funcionamiento

Your COLAMY recliner offers multiple features for enhanced comfort and convenience.

4.1 Función de reclinación

The chair features a power recline mechanism. Locate the two buttons on the side of the chair's armrest. Press the forward button to recline the chair up to 145 degrees. Press the backward button to return the chair to its upright position. Release the button at any point to stop the recline motion.

Image: Power recline and charging port control panel.

4.2 Swivel and Gliding Function

The chair is designed with a 270-degree swivel mechanism, allowing you to rotate the chair to your desired orientation. It also offers a smooth gliding motion for gentle rocking.

Image: The COLAMY recliner chair demonstrating its 270-degree swivel and gliding motion.

4.3 Device Holders

The chair includes two removable device holders, one for mobile phones and one for iPads. These holders attach to the support frame on the side of the chair. Adjust the clamps to securely hold your device. The iPad clip holds up to 1.33 pounds, and the phone clip holds up to 0.88 pounds.

4.4 Puertos de carga USB y tipo C

Conveniently located on the side of the chair, you will find both USB and Type-C charging ports. Use these ports to charge your electronic devices while relaxing in the chair.

4.5 Side Storage Pocket

A practical storage pocket is integrated into the side of the chair, perfect for holding magazines, remote controls, or other small items.

5. Mantenimiento

El cuidado adecuado prolongará la vida útil y la apariencia de su sillón reclinable.

• Limpieza: Para una limpieza general, limpie la superficie de cuero PU con un paño suave y seco.amp paño. Evite utilizar productos químicos fuertes o limpiadores abrasivos, ya que pueden dañar el material.
• Derrames: Absorba inmediatamente los derrames con un paño limpio y seco.
• Inspección: Revise periódicamente todos los pernos y conexiones para asegurarse de que estén bien apretados. Vuelva a apretarlos si es necesario.
• Luz del sol: Evite la exposición prolongada a la luz solar directa para evitar la decoloración y la degradación del material.

6. Solución de problemas

Si tiene algún problema con su sillón reclinable, consulte las siguientes soluciones comunes:

• Chair Not Reclining/Swiveling:
  • Ensure the power cable is securely connected to the chair and the wall outlet.
  • Compruebe si el tomacorriente de pared funciona enchufando otro dispositivo.
  • Verify that no objects are obstructing the reclining mechanism or swivel base.
• Device Holder Loose:
  • Tighten the Frame Nut (F) and ensure the device holder is securely attached to the Support Frame (C).
  • Ajustar el clamps on the device holder to firmly grip your phone or iPad.
• Ruidos inusuales:
  • Check for any loose bolts or connections and tighten them.
  • Asegúrese de que la silla esté sobre una superficie nivelada.

If the problem persists after attempting these solutions, please contact COLAMY customer support for further assistance.

7. Especificaciones

Detailed product specifications for the COLAMY 270 Power Swivel Glider Recliner Chair:

Imagen: Dimensiones detalladas del producto.

8. Garantía y soporte

For warranty information, specific return policies, or to contact customer support, please refer to the documentation included with your purchase or visit the official COLAMY website. Please have your model number (60399C-001) and purchase details ready when contacting support.
