1. Introducción
Thank you for choosing the COOAU 6MP Outdoor Security Camera. This manual provides detailed instructions for the installation, operation, and maintenance of your camera. Please read this manual carefully before use to ensure proper functionality and to maximize your security experience.
2. Producto terminadoview
Características principales
- 6MP High-Resolution & 360° Coverage: Equipped with a 6MP CMOS image sensor and 3360*1890P ultra-clear lens for sharp, detailed images. Features horizontal 350° and vertical 90° rotation for 360° monitoring without blind spots.
- Seguimiento automático: Automatically tracks and records movement upon human detection, ensuring no critical moments are missed.
- 20M Long-Range Night Vision & AI Human Detection: Features 3 infrared LEDs and light LEDs, offering two night vision modes (infrared black and white, full-color) up to 20m. AI human detection reduces false alarms from animals or light changes.
- Light Deterrent: Automatically activates a light alarm upon detecting intruders at night, preventing mischief.
- Multiple Data Storage Options & H.265 Video Compression: Supports MicroSD card (up to 128GB) and cloud storage. Advanced H.265 video compression saves up to 50% storage space compared to H.264 while maintaining video quality.
- Enhanced Antenna & Two-Way Audio: Powerful internal antenna provides stable and reliable Wi-Fi connection even through walls. Built-in microphone with noise cancellation allows clear two-way communication up to 8 meters.
- Resistencia a la intemperie IP66: Dustproof and waterproof, suitable for use in various weather conditions including rain, sun, storms, and snow.
- Compatibilidad con múltiples dispositivos: Compatible with iOS/Android/Windows via the "MIPC" app. Supports Alexa for voice control.
Contenido del paquete
- Camera body x 1
- Cable de alimentación USB x 1
- Adaptador de CA x 1
- Tornillos x 3
- Anclas x 3
- Manual de instrucciones x 1
3. Configuración
3.1 Comprobación previa a la instalación
Before physical installation, connect your mobile phone to the camera and confirm that the camera is functioning correctly. This ensures the camera is operational before mounting.
3.2 Instalación física
- Marcar agujeros de perforación: Place the mounting base against the desired installation surface and use a pencil to mark the positions for drilling.
- Perforación de agujeros: Use a drill to create holes at the marked positions.
- Inserting Wall Anchors: Gently tap the provided wall anchors into the drilled holes until they are flush with the surface.
- Montaje de la base: Align the mounting base with the anchors and secure it using the provided screws.
- Conexión de la cámara: Slide the camera onto the mounted base until it clicks securely into place.
- Conexión de energía: Connect the USB power cable to the camera and plug the AC adapter into a power outlet. The camera will perform a self-test, rotating its lens and emitting a beep sound. This is normal.
Image: Step-by-step guide for mounting the camera base and attaching the camera.
Video: Demonstrates the physical installation process of the outdoor security camera.
3.3 Instalación y conexión de la aplicación
- Descargar la aplicación: Download the "MIPC" app from your smartphone's app store (iOS/Android).
- Registrar Cuenta: Abra la aplicación y registre una nueva cuenta de usuario.
- Agregar dispositivo: Toque el ícono "+" para agregar un nuevo dispositivo.
- Enable Bluetooth (Optional): If prompted, enable Bluetooth on your smartphone to allow the app to automatically search for nearby cameras.
- Seleccionar red Wi-Fi: Choose your 2.4GHz or 5GHz Wi-Fi network and enter the password. The camera supports both frequencies.
- Escanear código QR: The app will display a QR code. Position your smartphone 15-25 cm in front of the camera lens so the camera can scan the QR code. You will hear a beep sound upon successful scan.
- Conexión completada: Once connected, the camera's blue indicator light will turn solid, and the app will confirm successful device addition.
Image: Visual guide for connecting the camera to the app via QR code.
Video: Instructions on how to add the camera to your smartphone app.
4. Instrucciones de funcionamiento
4.1 Monitoreo Remoto
Acceda a transmisiones de video en vivo y comidas grabadastage from anywhere using the MIPC app on your smartphone, tablet, or computer.
4.2 Control de panorámica, inclinación y zoom (PTZ)
Use the app to remotely adjust the camera's viewÁngulo de visión. La cámara admite un giro horizontal de 350° y una inclinación vertical de 90°, lo que le permite cubrir un área amplia.
Image: Illustrates the camera's 360° pan and tilt capabilities.
4.3 Modos de visión nocturna
La cámara ofrece dos modos de visión nocturna:
- Infrared Black and White: Proporciona video nítido en blanco y negro en condiciones de poca luz utilizando LED infrarrojos.
- Visión nocturna a todo color: Activates light LEDs to capture full-color video at night, allowing for detailed identification of subjects and their clothing.
Image: Comparison of black and white infrared night vision and full-color night vision.
4.4 Detección humana con IA y seguimiento automático
The camera's AI human detection feature accurately identifies human figures, minimizing false alarms from pets, shadows, or vehicles. When a person is detected, the camera automatically tracks their movement, ensuring continuous recording of the event.
Image: Demonstrates the camera's AI human detection accuracy.
Image: The camera's auto-tracking function following a person.
4.5 Audio bidireccional
Utilize the built-in microphone and speaker for real-time two-way communication through the app. This allows you to speak to visitors or deter intruders remotely.
4.6 Alarm Notifications & Light Deterrent
Receive real-time notifications on your smartphone when motion or human activity is detected. At night, the camera can automatically activate its light LEDs to deter potential intruders.
Image: The camera's light deterrent function in action.
4.7 Grabación y almacenamiento
La cámara admite varios modos de grabación:
- Grabación continua de 24 horas: Graba continuamente durante todo el día.
- Grabación por detección de movimiento: Graba sólo cuando se detecta movimiento.
- Grabación programada: Registros durante horarios específicos.
Recorded videos can be stored on a MicroSD card (up to 128GB, not included) or via cloud storage (subscription may be required). The advanced H.265 video compression ensures efficient storage usage without compromising video quality.
Image: Illustrates the flexible storage options available for the camera.
4.8 Integración con Alexa
The camera is compatible with Alexa, allowing you to view live feeds on compatible Alexa-enabled devices using voice commands. For example, say "Alexa, show me the garden" to see your camera's view.
Image: Demonstrates Alexa integration for convenient monitoring.
5. Mantenimiento
- Limpieza de la lente: Limpie regularmente la lente de la cámara con un paño suave y seco para garantizar una calidad de imagen nítida. Evite el uso de productos químicos agresivos.
- Comprobando conexiones: Periodically inspect all cable connections for security and integrity, especially the power and network cables.
- Actualizaciones de firmware: Check the MIPC app regularly for available firmware updates to ensure your camera has the latest features and security enhancements.
6. Solución de problemas
6.1 Problemas comunes
- La cámara no se conecta a Wi-Fi: Ensure your Wi-Fi password is correct and the camera is within range of your router. Try restarting both the camera and your router.
- Mala calidad de imagen: Check if the lens is clean. Ensure there is sufficient lighting, especially at night. Verify your internet connection speed.
- Falsas alarmas frecuentes: Adjust the sensitivity of motion detection or enable AI human detection in the app settings to reduce unwanted alerts.
- Sin audio: Check the microphone and speaker settings in the app. Ensure the volume on your smartphone is turned up.
6.2 Restablecer la cámara
If you encounter persistent issues, you may need to reset the camera to its factory settings. Locate the reset button (usually a small pinhole) on the camera. Press and hold the reset button for approximately 5 seconds until you hear a beep sound. The camera's red indicator light will slowly flash, indicating a successful reset. After resetting, you will need to reconfigure the camera through the app.
Video: Demonstrates how to reset the camera and its initial self-test.
7. Especificaciones
| Característica | Especificación |
|---|---|
| Nombre del modelo | 849 |
| Resolución de captura de video | 6MP (3360*1890P) |
| Rango de movimiento horizontal y vertical | Horizontales 350°, Verticales 90° |
| Rango de visión nocturna | Hasta 20 metros |
| Clasificación de impermeabilidad | IP66 |
| Tecnología de conectividad | Wireless (Wi-Fi, supports 2.4GHz & 5GHz) |
| Opciones de almacenamiento | MicroSD card (Max 128GB), Cloud Storage |
| Compresión de vídeo | H.265 |
| Dimensiones del producto | 45 x 55 x 75 mm |
| Peso del producto | 470 gramos |
| Uso recomendado | Seguridad del hogar |
| Dispositivos compatibles | Smartphones (iOS/Android), Alexa |
8. Garantía y soporte
We offer a 30-day return or exchange policy from the date of purchase. If you encounter any product quality issues or usage problems, please do not hesitate to contact us. We are committed to providing our customers with the highest level of after-sales service.
Canales de contacto:
- Historial de pedidos: Please contact the seller directly through your order history.
- Correo electrónico oficial: You may also contact us via our official email address.
